FRONT AXLE HOUSING & DIFFERENTIAL

0001 1 0002 1 0003 1 0004 1

31105CASE SUB-ASSY, TRANSAXLE(MTM)

main31105-16011iAL2#..MTM198205-198408

sub31105-16012

main31105-16012iAL25198408-198801

31105APLUG, TIGHT(FOR FRONT TRANSAXLE CASE)

main90331-29001iAL20..4F198205-198408

31105BBOLT, HEXAGON(FOR DIFFERENTIAL BEARING CAP SETTING)

main90105-10008iAL2#..MTM198205-198801

31105CPIN, STRAIGHT(FOR TRANSAXLE CASE)

main90250-10232iAL2#..MTM198205-198801

31110APLUG(FOR DIFFERENTIAL FILLER)

main90341-18006iAL2#..MTM198205-198801

31110BPLUG(FOR DIFFERENTIAL DRAIN)

main90341-18057iAL2#..MTM198205-198801

31110CGASKET(FOR DIFFERENTIAL FILLER)

main12157-10010iAL2#..MTM198205-198801

31110DGASKET(FOR DIFFERENTIAL DRAIN)

main12157-10010iAL2#..MTM198205-198801

3302

33101FRING, O(FOR INPUT FRONT)

main90301-54002iAL2#..MTM198205-198801

41110FCARRIER ASSY, DIFFERENTIAL, FRONT

main41110-16021iAL20,21..MTM198205-198408

R=41:11,*AXC=Y302

main41110-16050iAL20,21..3FC198205-198408

R=41:11, *AXC=Y302

main41110-16110iAL25198208-198408

R=41:11

main41110-16120iAL25198408-198801

41181COVER, FRONT DIFFERENTIAL CARRIER

main41181-16020iAL2#198205-198801

41181AGASKET, FRONT DIFFERENTIAL CARRIER COVER

main41182-16010iAL2#198205-198801

9033120044

main90331-20044

9161160820

main91611-60820

9161961250

main91619-61250

9162160614

main91621-60614

17 parts on this diagram · 4 diagrams in section
