CAUTION PLATE

33621APLATE, CONTROL LEVER CAUTION

main33621-60310iFJ80,HDJ80,HZJ80..ATM199001-199208

sub33621-60311

35519PLATE, AUTOMATIC TRANSMISSION CAUTION

main35519-60040iFZJ80,HDJ80..RHD..ATM199010-199703

main35519-60041iFZJ80..RHD199703-199801

main35519-60070iFJ80,FZJ80,HDJ80,HZJ80..LHD..ATM199010-199703

main35519-60071iFZJ80..LHD..ATM199703-199801

36369LABEL, TRANSFER INFORMATION

main36369-60090iHDJ80..RHD..MTM199010-199108

main36369-60110iHDJ80..RHD..ATM199010-199108

main36369-60180iFZJ80,HDJ80,HZJ80..MTM199503-199605

main36369-60190iFJ80,HDJ80,HZJ80..LHD..ATM199010-199108

main36369-60300iFZJ80,HDJ80..MTM..LUB199501-199605

W/O(CENTER DIFFERENTIAL LOCK)

main36369-60320iFZJ80,HDJ80..ATM199305-199605

W/O(CENTER DIFFERENTIAL LOCK)

main36369-60380iFZJ80,HDJ80,HZJ80199605-199801

sub36369-60470

main36369-60400iFZJ80,HDJ80..LHD..(GX,VX)199605-199801

W/O(CENTER DIFFERENTIAL LOCK)

41991APLATE, CAUTION

main41991-60060iFJ80,HDJ80,HZJ80199001-199002

main41991-60061iFJ80,FZJ80,HDJ80,HZJ80199002-199410

45197ALABEL, AIRBAG CAUTION

main45197-60020iFZJ80,HDJ80..GX,VX199501-199608

47939APLATE, LOAD SENSING VALVE MARKING

main47939-60130iFJ80,HDJ80,HZJ80..GX,VX199001-199208

main47939-60140iFJ80,HDJ80..VX199001-199208

W(3RD TRANSVERS SEAT)

main47939-60220iHZJ80..STD199001-199208

main47939-60240iHZJ80..STD199208-199501

main47939-60250iFZJ80,HDJ80,HZJ80..GX,VX199208-199501

main47939-60251iFZJ80,HDJ80..GX,STD199501-199605

main47939-60252iFZJ80,HDJ80..GX,STD199605-199801

main47939-60260iHZJ80..LUB;FZJ80,HDJ80..GX199208-199501

W(3RD TRANSVERS SEAT)

main47939-60261iFZJ80,HDJ80..VX199501-199605

W(3RD TRANSVERS SEAT)

main47939-60262iFZJ80,HDJ80..VX199605-199801

69339APLATE, CHILD PROTECTOR LOCK CAUTION

main69339-12010iFJ80,HZJ80..SOB199108-199208

69339BPLATE, CHILD PROTECTOR LOCK CAUTION

main69339-91704iFJ80,FZJ80,HDJ80,HZJ80..LUB199001-199801

sub69339-60020

74529PLATE, CHILD PROOF OR CHILD PROTECTOR LOCK CAUTION

main69339-12010iHZJ80..SOB199208-199501

W(3RD PARALLEL SEAT)

74544ELABEL, REAR NO.2 SEAT INFORMATION

main74544-60090iHZJ80..LUB;FZJ80,HDJ80199208-199501

74552PLATE, SAFETY CAUTION

main74582-60070iFJ80199001-199208

main74582-60080iHZJ80..STD199001-199605

main74582-60081iHZJ80..STD199605-199801

main74582-60090iHDJ80,HZJ80..GX199001-199208

main74582-60100iHDJ80..VX199001-199208

main74582-60570iFZJ80199208-199501

main74582-60590iHDJ80199208-199501

main74582-60591iFZJ80,HDJ80..GX,VX199605-199801

main74582-60620iHZJ80..GX;FZJ80,HDJ80..STD199208-199605

main74582-60621iHZJ80..GX;FZJ80,HDJ80..STD199605-199801

74559APLATE, FUEL CAUTION

main74559-14050iFJ80,FZJ80199001-199801

main74559-89101iHDJ80,HZJ80199001-199208

74597LABEL, DRIVER & PASSENGER AIRBAG CAUTION

main74597-60020iFZJ80,HDJ80..LHD..(GX,VX)199501-199608

main74597-60040iFZJ80,HDJ80199708-199801

13 parts on this diagram · 1 diagram in section
