TRANSFER VALVE BODY & VALVE LEVER

0001 1 0004 1 0007 1 0008 1 0009 1 0010 1

38227PLATE, WINCH CLUTCH LEVER SHIFT LOCK

main38227-60010iBJ4#,FJ40,43,45,55,HJ45196903-198007

38302ROLLER SUB-ASSY, WINCH WIRE GUIDE

main38302-60010iBJ4#,FJ40,43,45,55,HJ45196903-198007

38313MEMBER, FRONT BASE

main38313-60010iBJ4#,FJ4#,HJ45..4F196903-198007

main38313-60020iFJ55196903-198007

38314MEMBER, REAR BASE

main38314-60010iBJ4#,FJ40,43,45,55,HJ45196903-198007

38317SUPPORT, ROLLER BRACKET, NO.1

main38317-60010iBJ4#,FJ40,43,45,55,HJ45196903-198007

38318SUPPORT, ROLLER BRACKET, NO.2

main38318-60010iBJ4#,FJ40,43,45,55,HJ45196903-198007

38321SHAFT, WINCH ROLLER

main38321-60010iBJ4#,FJ40,43,45,55,HJ45196903-198007

38321ANUT, HEXAGON (FOR WINCH ROLLER SHAFT)

main90170-14057iBJ4#,FJ40,43,45,55,HJ45196903-198007

38324ROLLER, WINCH WIRE GUIDE, NO.2

main38324-60010iBJ4#,FJ40,43,45,55,HJ45196903-198007

MECHANICAL

main38324-60040iBJ4#,FJ4#,HJ45197910-198007

ELECTRIC

38324ASPACER, WINCH WIRE GUIDE ROLLER

main90560-13080iBJ4#,FJ40,43,45,55,HJ45196903-198007

38324BBOLT, HEXAGON (FOR WINCH WIRE GUIDE ROLLER)

main90101-12081iFJ40,43,45,55196903-196908

main90101-12284iBJ4#,FJ40,43,45,55,HJ45196908-198007

ISO

38325BRACKET, WINCH ROLLER, NO.1

main38325-60010iFJ40,43,45,55196903-196908

sub38325-60011

sub90101-12284

main38325-60011iBJ4#,FJ40,43,45,55,HJ45196908-197901

ISO

main38325-60011iFJ4#..4F;BJ4#,FJ55,HJ45197901-198007

MECHANICAL

main38325-60040iBJ4#,FJ4#,HJ45197910-198007

ELECTRIC

38326BRACKET, WINCH ROLLER, NO.2

main38326-60010iFJ40,43,45,55196903-196908

sub38326-60011

sub90101-12284

main38326-60011iBJ4#,FJ40,43,45,55,HJ45196908-198007

ISO

9111140820

main91111-40820

9111141025

main91111-41025

9111141032

main91111-41032

9411040800

main94110-40800

9451200800

main94512-00800

9451201000

main94512-01000

9451201200

main94512-01200

20 parts on this diagram · 6 diagrams in section
