REAR DISC BRAKE CALIPER & DUST COVER

0001 1 0003 1 0004 1 0005 1

04479ACYLINDER KIT, DISC BRAKE, REAR

main04479-60030iHZJ71,74199001-200108

04492PAD KIT, DISC BRAKE, REAR

main04492-60010iHZJ70,73,KZJ70,73,LJ7#,RJ7#..LX,VX199001-199505

sub04466-60010

31478CCAP, BLEEDER PLUG(FOR REAR DISC BRAKE)

main31478-30010iHZJ70,73,KZJ70,73,LJ7#,RJ7#..LX,VX199001-200108

47547CPLUG, BLEEDER(FOR REAR DISC BRAKE)

main47547-12030iPZJ70,73;HZJ70,71,73,74,LJ70,73,RJ7#..LX,VX199001-200108

47713APLUG, HOLE(FOR REAR DISC BRAKE CYLINDER)

main90950-01301iPZJ70,73;HZJ70,71,73,74,LJ70,73,RJ7#..LX,VX199001-200108

47715CPIN, CYLINDER SLIDE(FOR REAR DISC BRAKE)

main47715-22010iPZJ70,73;HZJ70,71,73,74,LJ70,73,RJ7#..LX,VX199001-200001

main47715-43010iHZJ71,74200001-200108

47716APLATE, PAD SUPPORT, NO.1(FOR REAR DISC BRAKE)

main47716-22010iPZJ70,73;HZJ70,71,73,74,LJ70,73,RJ7#..LX,VX199001-200108

47717APLATE, PAD SUPPORT, NO.2(FOR REAR DISC BRAKE)

main47717-22010iPZJ70,73;HZJ70,71,73,74,LJ70,73,RJ7#..LX,VX199001-200108

47721CMOUNTING, REAR DISC BRAKE CYLINDER, RH

main47721-60010iPZJ70,73;HZJ70,73,LJ70,73,RJ7#..LX,VX199001-199210

main47721-60020iHZJ70,71,73,74,LJ70,73,RJ7#..LX,VX199210-200108

47722AMOUNTING, REAR DISC BRAKE CYLINDER, LH

main47722-60010iPZJ70,73;HZJ70,73,LJ70,73,RJ7#..LX,VX199001-199210

main47722-60020iHZJ70,71,73,74,LJ70,73,RJ7#..LX,VX199210-200108

47730BCYLINDER ASSY, REAR DISC BRAKE, RH

main47730-60040iPZJ70,73;HZJ70,73,LJ70,73,RJ7#..LX,VX199001-199210

sub47730-60070

main47730-60070iHZJ70,73,LJ70,73,RJ7#..LX,VX199210-199801

sub47730-60110

main47730-60110iHZJ70,73199801-200108

47731BPISTON, REAR DISC BRAKE

main47731-60020iPZJ70,73;HZJ70,71,73,74,LJ70,73,RJ7#..LX,VX199001-200108

47744CSHIM, ANTI-SQUEAL, NO.1(FOR REAR DISC BRAKE)

main47744-60010iPZJ70,73;HZJ70,73,LJ70,73,RJ7#..LX,VX199001-199908

47750ACYLINDER ASSY, DISC BRAKE, REAR LH

main47750-60040iPZJ70,73;HZJ70,73,LJ70,73,RJ7#..LX,VX199001-199210

sub47750-60070

main47750-60070iHZJ70,73,LJ70,73,RJ7#..LX,VX199210-199801

sub47750-60110

main47750-60110iHZJ70,73199801-200108

47771APLATE, PAD WEAR INDICATOR(FOR REAR DISC BRAKE)

main47771-22030iPZJ70,73;HZJ70,71,73,74,LJ70,73,RJ7#..LX,VX199001-200108

47777PROTECTOR, DUST BOOT, RH

main47777-60010iPZJ70,73;HZJ70,71,73,74,LJ70,73,RJ7#..LX,VX199001-200108

47787APROTECTOR, DUST BOOT, LH

main47777-60010iPZJ70,73;HZJ70,71,73,74,LJ70,73,RJ7#..LX,VX199001-200108

47810ABOLT, HEXAGON(FOR REAR CALIPER)

main90101-12167iPZJ70,73;HZJ70,71,73,74,LJ70,73,RJ7#..LX,VX199001-200108

9011006007

main90110-06007

9020112452

main90201-12452

9451100600

main94511-00600

21 parts on this diagram · 4 diagrams in section
