ROOF PANEL & BACK PANEL

0001 1 0002 1W(ROOF AIR DEFLECTOR) 0003 1W(ROOF RACK)

53764ABRACKET, AIR CLEANER INLET, NO.1

main53764-37050iXZU300,320,330,340199907-200212

53765BBRACKET, AIR CLEANER INLET, NO.2

main53765-37040iXZU300,320,330,340199907-200212

53773BBRACKET, AIR CLEANER INLET, NO.2

main53773-37070iXZU300,320,330,340199907-200212

58930BBAND ASSY, ENGINE SERVICE HOLE COVER SUPPORT

main58930-37020iXZU300,320,330,340199907-200212

58935ABRACKET, ENGINE SERVICE HOLE COVER SUPPORT BAND

main58935-37020iXZU300,320,330,340199907-200212

58993CBRACKET, CONSOLE BOX MOUNTING, REAR

main58993-37050iXZU302,307,342200010-200206

63111PANEL, ROOF

main63111-37120iXZU302,307,320,342199907-200212

main63111-37130iXZU30#,330,34#..WT199907-200212

HIGH ROOF

sub63111-37131

63132PANEL, WINDSHIELD HEADER, INNER

main63132-37070iXZU302,307,320,342199907-200212

sub63132-37071

main63132-37080iXZU300,330,340199907-200009

sub63132-37081

main63132-37081iXZU30#,330,34#..WT200009-200212

HIGH ROOF

sub63132-37082

63141GREINFORCEMENT, ROOF PANEL, NO.1

main63141-37060iXZU320199907-200212

main63141-37070iXZU300,330,340199907-200212

HIGH ROOF

63231BRACKET, ROOM LAMP

main63231-37010iXZU30#,320,330,34#199907-200212

64111APANEL, BACK

main64111-37370iXZU300,320,330,340199907-200009

sub64111-37371

main64111-37371iXZU30#,320,330,34#200009-200106

sub64111-37372

main64111-37372iXZU30#,320,330,34#200106-200212

sub64111-37373

64115BREINFORCEMENT, BACK PANEL

main64115-37120iXZU300,320,330,340199907-200009

sub64115-37121

main64115-37121iXZU30#,320,330,34#200009-200212

sub64115-37122

64149BRETAINER, BACK PANEL HEADREST

main64149-37010iXZU30#,320,330,34#199907-200212

64225AHANGER, REAR SEAT CUSHION SUPPORT

main64209-37010iXZU30#,320,330,34#199907-200212

NO.1

main64209-37020iXZU30#,320,330,34#199907-200106

NO.2

sub64209-37030

sub64209-37040

main64209-37030iXZU302,307,342200106-200206

NO.2

main64209-37040iXZU300,320,330,340200106-200212

NO.2

64277EBRACKET, BACK PANEL TRIM, LOWER

main64277-37010iXZU30#,320,330,34#199907-200212

64811GLASS, BACK WINDOW

main64811-37120iXZU30#,320,330,34#199907-200212

*TEM,T=3.5,GREEN

main64811-37130iXZU302,307,342200010-200206

*TEM,T=3.5,BRONZE

64831WEATHERSTRIP, BACK WINDOW GLASS

main64831-37040iXZU30#,320,330,34#199907-200212

sub64831-37041

9015980049

main90159-80049

9095001398

main90950-01398

9095001865

main90950-01865

20 parts on this diagram · 3 diagrams in section
