CAUTION PLATE & NAME PLATE (ENGINE)

11284PLATE, ENGINE BOLT INFORMATION

main11284-54040i2L..LN85..VWP198901-199403

11298PLATE, EMISSION CONTROL INFORMATION

main11298-54190i2L..LN85..VWP..LHD199110-199307

NORWAY SPEC

main11298-54190i2L..LN85..VWP..LHD199307-199511

FINLAND,NORWAY SPEC

17700CPLATE, AIR CLEANER CAUTION (FOR ENGINE MODEL)

main90917-07084i2L,2Y..LN85,YN85..VWP198901-199702

17791LABEL, MAINTENANCE INFORMATION

main17791-55010i2L..LN85..VWP199202-199702

17792PLATE, ENGINE VACUUM HOSE INFORMATION

main17792-72220i2Y..YN85..VWP198901-199003

main17792-73410i2Y..YN85..VWP199003-199410

1356410010LABEL, TIMING BELT REPLACEMENT INFORMATION

main13564-10010

6 parts on this diagram · 1 diagram in section
