REAR AXLE SHAFT & HUB

0001 1 0002 1 0003 1

04438CBOOT KIT, REAR DRIVE SHAFT

main04429-42020iACA23200503-200511

sub04429-42021

main04438-42020iACA21200008-200503

sub04438-42160

04438DBOOT KIT, REAR DRIVE SHAFT INBOARD JOINT

main04438-42010iACA21200008-200503

sub04438-42150

main04439-42020iACA23200503-200511

sub04439-42022

42330SHAFT ASSY, REAR DRIVE, RH

main42330-42030iACA21200008-200510

W(ABS)

sub42330-42031

main42330-42031iACA23200511

W(ABS)

main42330-42040iACA23..CND200008-200510

sub42330-42041

main42330-42041iACA23..CND200511

42340BSHAFT ASSY, REAR DRIVE, LH

main42340-12051iACA23..CND200008-200510

sub42340-12052

main42340-12052iACA23..CND200511

main42340-12061iACA21200008-200510

W(ABS)

sub42340-12062

main42340-12062iACA23200511

W(ABS)

42341BRING, SNAP (FOR REAR DRIVE SHAFT RH)

main90520-22005iACA21200008-200510

42341CRING, SNAP (FOR REAR DRIVE SHAFT LH)

main90520-22005iACA23200008-200510

42344ACOVER, REAR AXLE INBOARD JOINT END, RH

main42343-14010iACA21200008-200307

42344BCOVER, REAR AXLE INBOARD JOINT END, LH

main42343-14010iACA21200008-200307

42346CCLAMP (FOR REAR DRIVE SHAFT OUTBOARD JOINT BOOT RH)

main42345-52100iACA23200511

ID=85.2

sub42345-52250

main42345-52110iACA23200511

ID=27.0

sub42345-52260

main90949-01078iACA21200008-200511

ID=32.7

main90949-01080iACA21200008-200511

ID=88.2

42346DCLAMP (FOR REAR DRIVE SHAFT OUTBOARD JOINT BOOT LH)

main42345-52100iACA23200511

ID=85.2

sub42345-52250

main42345-52110iACA23200511

ID=27.0

sub42345-52260

main90949-01078iACA21200008-200511

ID=32.7

main90949-01080iACA21200008-200511

ID=88.2

42347CCLAMP (FOR REAR DRIVE SHAFT INBOARD JOINT BOOT RH)

main42345-14010iACA23200008-200510

ID=35.75

main42345-14020iACA23200008-200510

ID=93.97

42347DCLAMP (FOR REAR DRIVE SHAFT INBOARD JOINT BOOT LH)

main42345-14010iACA21200008-200510

ID=35.75

main42345-14020iACA23200008-200510

ID=93.97

42360CJOINT ASSY, REAR DRIVE SHAFT INBOARD, RH

main42350-42010iACA23200008-200511

sub42350-42020

42360DJOINT ASSY, REAR DRIVE SHAFT INBOARD, LH

main42350-42010iACA23200008-200511

sub42350-42020

42370ASHAFT ASSY, REAR DRIVE OUTBOARD JOINT, RH

main42370-49075iACA21200008-200511

W(ABS)

sub42370-49215

main42370-49085iACA21200008-200511

sub42370-49205

42380SHAFT ASSY, REAR DRIVE OUTBOARD JOINT, LH

main42370-49095iACA21200008-200511

W(ABS)

sub42370-19205

main42370-49105iACA21200008-200511

sub42370-19195

42451ADEFLECTOR, REAR WHEEL BEARING DUST, NO.1 RH

main42451-32010iACA21200008-200511

main43247-12010iACA21200008-200511

W(ABS)

42451BDEFLECTOR, REAR WHEEL BEARING DUST, NO.1 LH

main42451-32010iACA21200008-200511

main43247-12010iACA21200008-200511

W(ABS)

9017010191

main90170-10191

9020110068

main90201-10068

20 parts on this diagram · 3 diagrams in section
