REAR AXLE SHAFT & HUB

0001 1 0002 1 0003 1 0004 1W(ABS) 0005 1W(ABS) 0006 1

04438CBOOT KIT, REAR DRIVE SHAFT

main04438-42020iSXA10,11199511-199709

sub04438-42160

04438DBOOT KIT, REAR DRIVE SHAFT INBOARD JOINT

main04438-42010iSXA10,11199511-199709

sub04438-42150

42330SHAFT ASSY, REAR DRIVE, RH

main42330-42010iSXA10,11199511-199709

sub42330-42011

sub90178-22001

main42330-42011iSXA10,11199709

sub42330-42012

main42330-42020iSXA10,11199511-199709

W(ABS)

sub42330-42021

sub90178-22001

main42330-42021iSXA10,11199709

W(ABS)

sub42330-42022

42340BSHAFT ASSY, REAR DRIVE, LH

main42340-42010iSXA10,11199511-199709

sub42340-42011

sub90178-22001

main42340-42011iSXA10,11199709

sub42340-42012

main42340-42020iSXA10,11199511-199709

W(ABS)

sub42340-42021

sub90178-22001

main42340-42021iSXA10,11199709

W(ABS)

sub42340-42022

42341BRING, SNAP (FOR REAR DRIVE SHAFT RH)

main90520-22005iSXA10,11199511

42344ACOVER, REAR AXLE INBOARD JOINT END, RH

main42343-14010iSXA10,11199511

42344BCOVER, REAR AXLE INBOARD JOINT END, LH

main42343-14010iSXA10,11199511

42346CCLAMP (FOR REAR DRIVE SHAFT OUTBOARD JOINT BOOT RH)

main90949-01078iSXA10,11199511-200008

ID=32.7

main90949-01080iSXA10,11199511-200008

ID=88.2

42346DCLAMP (FOR REAR DRIVE SHAFT OUTBOARD JOINT BOOT LH)

main90949-01078iSXA10,11199511-200008

ID=32.7

main90949-01080iSXA10,11199511-200008

ID=88.2

42347CCLAMP (FOR REAR DRIVE SHAFT INBOARD JOINT BOOT RH)

main42345-14020iSXA10,11199511

ID=93.97

main42345-16030iSXA10,11199511

ID=35.75

42347DCLAMP (FOR REAR DRIVE SHAFT INBOARD JOINT BOOT LH)

main42345-14020iSXA10,11199511

ID=93.97

main42345-16030iSXA10,11199511

ID=35.75

42360CJOINT ASSY, REAR DRIVE SHAFT INBOARD, RH

main42350-42010iSXA10,11199511

sub42350-42020

42360DJOINT ASSY, REAR DRIVE SHAFT INBOARD, LH

main42350-42010iSXA10,11199511

sub42350-42020

42370ASHAFT ASSY, REAR DRIVE OUTBOARD JOINT, RH

main42370-49015iSXA10,11199511-199709

sub42370-49016

sub90178-22001

main42370-49016iSXA10,11199709

sub42370-49225

main42370-49025iSXA10,11199511-199709

W(ABS)

sub42370-49026

sub90178-22001

main42370-49026iSXA10,11199709

W(ABS)

sub42370-49235

42380SHAFT ASSY, REAR DRIVE OUTBOARD JOINT, LH

main42380-49015iSXA10,11199511-199709

sub42380-49016

sub90178-22001

main42380-49016iSXA10,11199709

sub42380-49035

main42380-49025iSXA10,11199511-199709

W(ABS)

sub42380-49026

sub90178-22001

main42380-49026iSXA10,11199709

W(ABS)

sub42380-49045

42451ADEFLECTOR, REAR WHEEL BEARING DUST, NO.1 RH

main42451-32010iSXA10,11199511

main43247-12010iSXA10,11199511

W(ABS)

42451BDEFLECTOR, REAR WHEEL BEARING DUST, NO.1 LH

main42451-32010iSXA10,11199511

main43247-12010iSXA10,11199511

W(ABS)

9017010191

main90170-10191

9020110068

main90201-10068

19 parts on this diagram · 6 diagrams in section
