SWITCH & RELAY & COMPUTER

0001 1ENGINE & TRANSMISSION 0002 1ENGINE & TRANSMISSI0N 0003 1ENGINE & TRANSMISSION 0004 1ENGINE ROOM 0005 1COWL 0006 1COWL 0007 1COWL 0008 1COWL 0009 1INSTRUMENT PANEL 0010 1INSTRUMENT PANEL 0011 1INSTRUMENT PANEL 0012 1INSTRUMENT PANEL 0013 1IGNITION & COMBINATION SWITCH0014 1IGNITION & COMBINATION SWITCH0015 1IGNITION & CONBINATION SWITCH0016 1DOOR,ROOF & FLOOR 0017 1DOR,ROOF & FLOOR

3304

3505

83181GSENSOR, SPEEDOMETER

main83181-12030iACR30,CLR30..MTM200002-200304

main83181-12040iACR30..ATM200002-200304

83181HRING, O (FOR SPEEDOMETER SENSOR)

main96711-24018iACR30..08S..ATM;ACR30,CLR30..06S,07S200304

83530SWITCH ASSY, OIL PRESSURE (FOR ENGINE)

main83530-28020iACR30200002-200304

DENSO

main83530-60010iCLR30200102-200304

main83530-60020iACR30200304-200601

YAZAKI

84210SWITCH ASSY, BACK-UP LAMP

main84210-12040iACR30,CLR30..MTM200002-200304

sub84210-52050

84540SWITCH ASSY, NEUTRAL START

main84540-12230iACR30..ATM200002-200304

PART NUMBER LABEL=84540-12230

main84540-32110iACR30..ATM200303-200304

PART NUMBER LABEL=84540-32110

main84540-48010iACR30..ATM200304-200601

89428SWITCH, TEMPERATURE DETECT, NO.2

main89428-20110iACR30,CLR30200002-200304

89465SENSOR, OXYGEN

main89465-28220iACR30..ARL,GCC200002-200304

BANK1

main89465-28230iACR30..ARL,GCC200002-200304

BANK2

main89465-28280iACR30..EUR,GEN200002-200304

BANK1

main89465-28290iACR30..EUR,GEN200002-200304

BANK2

main89465-28340iACR30200304-200601

SENSOR2

89467BSENSOR, AIR FUEL RATIO

main89467-28030iACR30..EUR,GEN200002-200304

BANK1

main89467-28040iACR30..EUR,GEN200002-200304

BANK2

main89467-28120iACR30200304-200601

SENSOR1

89491SENSOR, ENGINE OIL LEVEL

main89491-28070iACR30200002-200211

main89491-28071iACR30200304-200601

main89491-28080iCLR30200304-200601

89491AGASKET, ENGINE OIL LEVEL SENSOR

main89493-60010iACR30,CLR30200002-200304

89615SENSOR, KNOCK CONTROL

main89615-20090iACR30200304-200601

main89615-30080iACR30200002-200105

MATSUSHITA

main89615-32030iACR30200002-200105

DENSO

main89615-44010iACR30200105-200304

827112B660WIRE, FUSE TO FUSE(FOR COMBUSTION HEATER)

main82711-2B660

8271528830BRACKET,WIRING HARNESS CLAMP

main82715-28830

8761642020CLAMP, COOLING UNIT CASE

main87616-42020

9017908025

main90179-08025

9043018008

main90430-18008

9165140625

main91651-40625

9165160614

main91651-60614

20 parts on this diagram · 17 diagrams in section
