FRONT PANEL & WINDSHIELD GLASS

53183CPACKING, HEADLAMP SERVICE HOLE COVER

main53183-87001iYR2#,31¥460198808-199001

53793COVER, HEADLAMP WIRE HARNESS HOLE, NO.1

main53793-87001iYR2#,31¥1,180198808-199001

53801JPANEL SUB-ASSY, FRONT SIDE, RH

main53801-87002iYR2#,31¥8,900198808-199001

53802JPANEL SUB-ASSY, FRONT SIDE, LH

main53802-87002iYR2#,31¥8,900198808-199001

53821APROTECTOR, FRONT SIDE PANEL, NO.1 RH

main53821-87002iYR2#,31¥810198808-199001

53827ARETAINER, FRONT SIDE PANEL SET

main53827-95700iYR2#,31¥540198808-199001

53827CPROTECTOR, FRONT SIDE PANEL, NO.4

main53827-87001iYR2#,31¥300198808-199001

53828BPROTECTOR, FRONT FENDER SIDE PANEL, LH

main53828-87002iYR2#,31¥810198808-199001

55105AMEMBER SUB-ASSY, FRONT PANEL

main55105-28010iYR2#,31..LHD¥23,700198808-199001

55174BRACKET, BRAKE PEDAL MOUNTING, NO.2

main55174-28010iYR22..GL;YR21,31..LHD¥1,510198808-199001

sub55174-28020¥1,510

main55174-28020iYR22..DLX¥1,510198808-199001

SWEDEN SPEC

55211ASILENCER, FRONT PANEL, UPPER

main55211-28010iYR2#,31..LHD¥270198808-199001

LH

main55211-87002iYR21..RHD¥1,830198808-199001

main55241-28010iYR2#,31..LHD¥310198808-199001

RH

55212ASILENCER, FRONT PANEL, LOWER

main55212-28010iYR2#,31..LHD¥310198808-199001

main55212-87002iYR21..RHD¥270198808-199001

55700PANEL ASSY, FRONT

main55701-28010iYR2#,31..LHD¥41,900198808-199001

main55701-87028iYR21..RHD¥48,100198808-199001

56111GLASS, WINDSHIELD

main56111-87010iYR2#,31¥99,900198808-199001

*TL,T=5.3

main56111-87011iYR2#,31¥87,800198808-199001

*LAM,T=5.3

sub56111-87009¥95,800

main56111-87013iYR2#,31..GL¥115,000198808-199001

*TL,T=5.3,BRONZE

56121WEATHERSTRIP, WINDSHIELD

main56121-87004iYR2#,31¥14,200198808-199001

main56121-87009iYR2#..GL¥15,600198808-199001

W(TWIN SUN ROOF)

58107BREINFORCEMENT SUB-ASSY, FRONT CROSS TO FRONT PANEL, RH

main58107-28010iYR2#,31..LHD¥2,050198808-199001

58108BREINFORCEMENT SUB-ASSY, FRONT CROSS TO FRONT PANEL, LH

main58108-28010iYR2#,31..LHD¥2,640198808-199001

8853987009HOSE, COOLER UNIT DRAIN, NO.1

main88539-87009¥600

9004468008

main90044-68008¥140

9046709003

main90467-09003¥170

9095001173

main90950-01173¥170

9165140612

main91651-40612¥70

9165160816

main91651-60816¥100

9166140612

main91661-40612¥130

9356014012

main93560-14012¥70

25 parts on this diagram · 1 diagram in section
