CAUTION PLATE & NAME PLATE (ENGINE)

11278PLATE, ENGINE EMISSION IDENTIFICATION

main11278-16020i4K..KM20..RHD..03S198505-198508

SINGAPORE SPEC

sub11278-42010

main11278-54010i1C..CM20..ARL198210-198508

11291PLATE, ENGINE NAME

main11291-13030i4K..KM20..ARL;4K..KM20..V4D..4F;4K..KM20..SRF..08S..STD197910-198508

main11291-13050i4K..KM20..V4D..02S..EUR;4K..KM20..(03S,05S,06S,08S,09S)..(EUR,GEN)197910-198508

main11291-71010i1Y..YM20198402-198508

main11291-72010i2YC..YM21198311-198508

11293PLATE, ENGINE CAUTION & ENGINE NAME

main11293-64010i1C..CM20198210-198508

11296PLATE, TIMING BELT CAUTION

main11296-54010i1C..CM20198210-198406

11297PLATE, ENGINE CAUTION, NO.3

main11297-13010i4K..KM20..RHD;4K..KM20..LHD..VSP..EUR;4K..KM20..LHD..(03S,05S,06S,07S)197910-198002

sub11297-71010

main11297-13020i4K..KM20..VSP..02S;4K..KM20..03S,05S,06S,07S,08S,09S198002-198210

11298PLATE, EMISSION CONTROL INFORMATION

main11298-13040i4K..KM20..ARL197910-198010

sub11298-13041

main11298-13042i4K..KM20..ARL198010-198107

main11298-13043i4K..KM20..ARL198107-198210

main11298-13043i4K..KM20..ARL198210-198508

4K-C

main11298-13050i4K..KM20..ARL198210-198508

4K

main11298-13180i4K..KM20..ARL;4K..KM20..V4D..4F;4K..KM20..SRF..08S198210-198409

SWITZERLAND SPEC

sub11298-13181

main11298-13182i4K..KM20..ARL;4K..KM20..V4D..4F;4K..KM20..SRF..08S198409-198508

SWITZERLAND SPEC

main11298-72050i2YC..YM21198311-198508

17700CPLATE, AIR CLEANER CAUTION (FOR ENGINE MODEL)

main17791-64020i1C..CM20198307-198508

main90917-07084i1Y,2YC..YM2#198311-198508

main90917-07088i1C..CM20198210-198307

17700DPLATE, ENGINE CAUTION

main11293-13050i4K..KM20..RHD;4K..KM20..LHD..VSP..EUR;4K..KM20..LHD..(03S,05S,06S,07S)197910-198004

sub11293-13051

main11293-13051i4K..KM20..RHD;4K..KM20..LHD..VSP..EUR;4K..KM20..LHD..(03S,05S,06S,07S,09S)198004-198101

sub11293-13052

main11293-13052i4K..KM20..ARL,GEN198101-198508

17739PLATE, AIR CLEANER PART NUMBER

main17739-13020i4K..KM20..RHD..EUR197910-198004

sub17739-13021

main17739-13021i4K..KM20..RHD..EUR198004-198008

17792PLATE, ENGINE VACUUM HOSE INFORMATION

main17792-13120i4K..KM20..ARL197910-198508

main17792-13130i4K..KM20..ARL197910-198508

main17792-13280i4K..KM20..V4D..4F198210-198508

SWITZERLAND SPEC

main17792-72100i2YC..YM21198311-198508

23923PLATE, FUEL SEDIMENTER CAUTION

main23923-64010i1C..CM20..ARL,GEN198210-198508

sub23923-64011

11 parts on this diagram · 1 diagram in section
