DISC WHEEL & WHEEL CAP
42601WHEEL, DISC
20X8J,#,TIRE & DISC WHEEL-235/55R20 SUMMER TIRE,TYPE D:REFER ILLUST.
20X8J,#,TIRE & DISC WHEEL-235/55R20 SUMMER TIRE MACHINING,TYPE D:REFER ILLUST.
20X8J,#,TIRE & DISC WHEEL-235/55R20 SUMMER TIRE SELECTORBULL,TYPE E:REFER ILLUST.
18X8J,#,INDIA SPEC&SPARE TIRE-GROUND TIRE,TYPE I:REFER ILLUST.
18X8J,#,TYPE I:REFER ILLUST.
18X8J,#,INDIA SPEC&SPARE TIRE-GROUND TIRE,TYPE G:REFER ILLUST.
18X8J,#,TYPE G:REFER ILLUST.
20X8J,#,TIRE & DISC WHEEL-235/55R20 SUMMER TIRE BRONZE COLORED,TYPE D:REFER ILLUST.
18X8J,#,TYPE A:REFER ILLUST.
18X8J,#,TYPE B:REFER ILLUST.
20X8J,#,TIRE & DISC WHEEL-235/55R20 SUMMER TIRE HIMETA,TYPE H:REFER ILLUST.
TIRE & DISC WHEEL-235/55R20 BLACK,TYPE H:REFER ILLUST.
42601AWHEEL, DISC (FOR SPARE)
18X4T,TURKEY SPEC&SPARE TIRE-S-TEMPORARY(T165/90D18),TYPE F:REFER ILLUST.
sub42611-48752
18X4T,ISRAEL SPEC&SPARE TIRE-S-TEMPORARY(T165/90D18),TYPE F:REFER ILLUST.
sub42611-48752
18X4T,SPARE TIRE-TEMPORARY(T165/90D18),TYPE F:REFER ILLUST.
sub42611-48752
18X4T,REUNION SPEC&SPARE TIRE-S-TEMPORARY(T165/90D18),TYPE F:REFER ILLUST.
sub42611-48752
18X4T,SPARE TIRE-TEMPORARY(T165/90D18),TYPE F:REFER ILLUST.
18X4T,TYPE F:REFER ILLUST.
18X4T,REUNION SPEC&SPARE TIRE-S-TEMPORARY(T165/90D18),TYPE F:REFER ILLUST.
18X4T,TURKEY SPEC&SPARE TIRE-S-TEMPORARY(T165/90D18),TYPE F:REFER ILLUST.
18X4T,ISRAEL SPEC&SPARE TIRE-S-TEMPORARY(T165/90D18),TYPE F:REFER ILLUST.
18X8J,#,INDIA SPEC&SPARE TIRE-GROUND TIRE,TYPE I:REFER ILLUST.
18X8J,#,INDIA SPEC&SPARE TIRE-GROUND TIRE,TYPE G:REFER ILLUST.
42601CNUT, HUB (FOR AXLE)
TIRE & DISC WHEEL-235/55R20 BLACK
42611JVALVE (FOR TUBELESS TIRE SPARE)
TURKEY SPEC&SPARE TIRE-S-TEMPORARY(T165/90D18),TYPE A:REFER ILLUST.
ISRAEL SPEC&SPARE TIRE-S-TEMPORARY(T165/90D18),TYPE A:REFER ILLUST.
SPARE TIRE-TEMPORARY(T165/90D18),TYPE A:REFER ILLUST.
REUNION SPEC&SPARE TIRE-S-TEMPORARY(T165/90D18),TYPE A:REFER ILLUST.
TYPE A:REFER ILLUST.
4 parts on this diagram · 2 diagrams in section
