SWITCH & RELAY & COMPUTER

0001 1ENGINE & TRANSMISSION 0002 1ENGINE & TRANSMISSION 0003 1ENGINE ROOM 0004 1ENGINE ROOM 0005 1ENGINE ROOM 0006 1ENGINE ROOM RELAY BLOCK 0007 1ENGINE ROOM RELAY BLOCK 0008 1ENGINE ROOM RELAY BLOCK 0009 1ENGINE ROOM RELAY BLOCK 0010 1COWL 0011 1COWL 0012 1INSTRUMENT PANEL 1/2 0013 1INSTRUMENT PANEL 1/2 0014 1INSTRUMENT PANEL 2/2 0015 1STEERING 0016 1STEERING 0017 1SEAT 0018 1DOOR & ROOF 0019 1FLOOR & LUGGAGE

83530SWITCH ASSY, OIL PRESSURE (FOR ENGINE)

main83530-28020iGWZ100,URZ100201705

DENSO,*369

main83530-60020iGWZ100,URZ100201705

YAZAKI,*369

89413ASENSOR, TRANSMISSION REVOLUTION

main89413-11010iGWZ100201705-201807

main89413-11011iGWZ100201808

89422ASENSOR, WATER TEMPERATURE

main89422-47010iGWZ100201705

89426ABRACKET, VACUUM SENSOR

main25715-31010iGWZ100202004

RH

main25716-31010iGWZ100202004

LH

main89426-11010iURZ100201809

RH

main89426-11020iURZ100201809

LH

89467BSENSOR, AIR FUEL RATIO

main89467-11010iGWZ100201705

FR LH

main89467-11020iGWZ100201705

FR RH

main89467-11030iGWZ100201705-202004

RR LH

main89467-11040iGWZ100201705-202004

RR RH

main89467-11050iURZ100201705

FR RH

main89467-11100iGWZ100202004

RR LH

main89467-11110iGWZ100202004

RR RH

main89467-24010iURZ100201705

FR LH

89481BSENSOR, DIFFERENTIAL PRESSURE

main89481-71010×2iURZ100201809

89491SENSOR, ENGINE OIL LEVEL

main89491-24020iURZ100201705

main89491-30100iGWZ100201705-201808

main89491-30101iGWZ100201809

89615SENSOR, KNOCK CONTROL

main89615-20090×2iGWZ100201705

827113F480WIRE, FUSE TO FUSE(FOR COMBUSTION HEATER)

main82711-3F480

8271511060BRACKET,WIRING HARNESS CLAMP

main82715-11060

8271511070BRACKET,WIRING HARNESS CLAMP

main82715-11070

8271544510BRACKET,WIRING HARNESS CLAMP

main82715-44510

8271550F30BRACKET,WIRING HARNESS CLAMP

main82715-50F30

8271550G10BRACKET,WIRING HARNESS CLAMP

main82715-50G10

9030111008

main90301-11008

9046814044

main90468-14044

9046815007

main90468-15007

9155180830

main91551-80830

91611B0614

main91611-B0614

9167180616

main91671-80616

9167180816

main91671-80816

9167180820

main91671-80820

9167380612

main91673-80612

9415180600

main94151-80600

24 parts on this diagram · 19 diagrams in section
