SWITCH & RELAY & COMPUTER

0001 1ENGINE & TRANSMISSION 0002 1ENGINE ROOM 0003 1ENGINE ROOM 0004 1ENGINE ROOM RELAY BLOCK 0005 1ENGINE ROOM RELAY BLOCK 0006 1COWL 0007 1COWL 0008 1INSTRUMENT PANEL 0009 1INSTRUMENT PANEL 0010 1IGNITION & COMBINATION SWITCH0011 1IGNITION & COMBINATION SWITCH0012 1SEAT 0013 1DOOR & ROOF 0014 1FLOOR & LUGGAGE 0015 1FLOOR & LUGGAGE

83530SWITCH ASSY, OIL PRESSURE (FOR ENGINE)

main83530-28020iGWS191200602-200709

DENSO

main83530-60020iGWS191200602-200709

YAZAKI

83531CSWITCH, OIL PRESSURE, (PB1)

main83531-30011iGWS191200709-201112

83531DSWITCH, OIL PRESSURE, (PB2)

main83531-30011iGWS191200709-201112

83531ESWITCH, OIL PRESSURE, (PB3)

main83531-30021iGWS191200602-200709

sub83531-30022

89465SENSOR, OXYGEN

main89465-30730×2iGWS191200602-200709

89467BSENSOR, AIR FUEL RATIO

main89467-30010iGWS191200602-200709

RH

main89467-30020iGWS191200602-200709

LH

89491SENSOR, ENGINE OIL LEVEL

main89491-30060iGWS191200602-200709

main89491-30061iGWS191201109-201112

89491AGASKET, ENGINE OIL LEVEL SENSOR

main89493-60010iGWS191200602-200709

89615SENSOR, KNOCK CONTROL

main89615-20090×2iGWS191200602-200709

827112B660WIRE, FUSE TO FUSE(FOR COMBUSTION HEATER)

main82711-2B660

8271135060WIRE, FUSE TO FUSE(FOR COMBUSTION HEATER)

main82711-35060

9155180830

main91551-80830

91621B0616

main91621-B0616

13 parts on this diagram · 15 diagrams in section
