THROTTLE LINK & VALVE LEVER (ATM)

0001 1A760E,A761E,A960E 0002 1AA80E 0003 1A760H

3312

35501ROD SUB-ASSY, PARKING LOCK

main35501-22030iGRS190..EUR200501-200709

main35501-50010iUZS190;GRS190..GCC,GEN200501-200709

main35501-50020iURS190200709

35505LEVER SUB-ASSY, MANUAL VALVE

main35505-22080iGRS190..EUR200501-200508

sub35505-53040

main35505-30040iURS190200709

main35505-50030iUZS190;GRS190..GCC,GEN200501-200508

sub35505-53030

main35505-53030iGRS196,UZS190;GRS190..GCC,GEN200508-200709

main35505-53040iGRS190..EUR200508-200709

35506CPIN, SLOTTED SPRING (FOR MANUAL VALVE LEVER SHAFT)

main90254-04011iGRS190,UZS190200501-200709

35506FSEAL, OIL (FOR MANUAL VALVE LEVER SHAFT)

main90311-12002iGRS190,UZS190200501-200709

35506HSPACER (FOR MANUAL VALVE LEVER SHAFT)

main90560-20025iGRS190,UZS190200501-200709

35556SHAFT, PARKING LOCK PAWL

main35556-60020iGRS19#,URS190,UZS190200501-200709

35556ERING, E (FOR PARKING LOCK PAWL SHAFT)

main90523-08021iGRS190,UZS190200501-200709

35557PAWL, PARKING LOCK

main35590-50010iGRS190,UZS190200501-200709

sub35590-50030

main35590-50020iURS190200709

35557ASPRING, TORSION (FOR PARKING LOCK PAWL)

main90949-03130iUZS190;GRS190..GCC,GEN200501-200709

main90949-03137iGRS190..EUR200501-200709

35561SHAFT, MANUAL VALVE LEVER

main35561-50020iGRS190,UZS190200501-200709

main35561-50030iURS190200709

main35561-60030iGRS196200907

35572LEVER, TRANSMISSION CONTROL SHAFT, RH

main35572-30070iGRS190,UZS190200501-201112

main35572-30100iURS190200709-201112

35595BRACKET, PARKING LOCK PAWL

main35595-50010iGRS190,UZS190200501-200709

main35595-50020iURS190200709

91611B0614

main91611-B0614

9413000802

main94130-00802

9451200800

main94512-00800

16 parts on this diagram · 3 diagrams in section
