CAUTION PLATE & NAME PLATE (ENGINE)

11278PLATE, ENGINE EMISSION IDENTIFICATION

main11278-16010i1GE..GX71..RHD198503-198608

SINGAPORE SPEC

main11278-16020i21R..RX70..RHD..GL198608-198808

SINGAPORE SPEC

sub11278-42010

11284PLATE, ENGINE BOLT INFORMATION

main11284-54010i2L..LX70198807-198808

11288PLATE, ENGINE SYSTEM

main11288-88301i1GGE..GX71198408-198608

11291PLATE, ENGINE NAME

main11291-35030i22R..RX72,73198608-198808

22R

main11291-37040i21R..RX70,71198408-198705

21R

main11291-43020i5ME..MX7#198408-198808

5M-E

main11291-70020i1GE..GX71198408-198808

1G-E

main11291-72010i2Y..YX70198502-198808

2Y

main11291-88300i1GGE..GX71198408-198608

1G-GE

11293PLATE, ENGINE CAUTION & ENGINE NAME

main11293-37050i21R,22R..RX70,72..LHD..GEN198510-198705

CHINA SPEC

main11293-54030i2L..LX70198408-198808

main11293-54050i2LT..LX7#198408-198608

main11293-54080i2L..LX70198505-198808

CHINA SPEC

main11296-35010i22R..RX72..LHD..GEN198705-198808

CHINA SPEC

11294PLATE, ENGINE CAUTION, NO.2

main11294-64020i2LT..LX7#198408-198608

sub11294-64050

11296PLATE, TIMING BELT CAUTION

main11296-54010i2L#..LX7#198408-198411

11298PLATE, EMISSION CONTROL INFORMATION

main11298-43160i5ME..MX73..ARL198408-198508

main11298-43200i5ME..MX7#..SWZ198408-198608

main11298-43210i5MGE..MX73..ARL198508-198602

sub11298-43211

main11298-43211i5MGE..MX73..ARL198602-198808

17627PLATE, AIR PUMP CAUTION, NO.1

main90917-07066i5ME..MX7#..ARL,EUR198408-198608

17700CPLATE, AIR CLEANER CAUTION (FOR ENGINE MODEL)

main17791-28010i5MGE..MX73..ARL198408-198808

sub17791-16040

main17791-54040i2L..LX70198505-198808

CHINA SPEC

main17791-64020i21R,22R,2L..LX70,RX7#198408-198808

main90917-07084i2Y..YX70198502-198808

17700DPLATE, ENGINE CAUTION

main11293-43050i5MGE..MX73..GEN198411-198508

main11293-43080i5MGE..MX73..EUR,SA198408-198808

main11293-43150i5ME..MX73..GEN,ME198411-198808

main11293-70080i1GE..GX71198408-198808

main11293-70090i1GGE..GX71198408-198608

main11299-43010i5ME..MX7#..SWZ198408-198608

17792PLATE, ENGINE VACUUM HOSE INFORMATION

main17792-35810i22R..RX72..ME198608-198808

main17792-37160i21R..RX70..ME198508-198608

main17792-37160i21R..RX70..ME198408-198508

SAUDI ARABIA SPEC

main17792-37160i21R..RX70..RHD..GL198408-198608

SINGAPORE SPEC

main17792-37170i21R..RX70..RHD..GL198608-198705

SINGAPORE SPEC

main17792-43100i5ME..MX73..5F..SWZ198408-198608

main17792-43110i5ME..MX7#..4FC..(ARL,EUR)198408-198608

23923PLATE, FUEL SEDIMENTER CAUTION

main23923-54010i2L..LX70198408-198505

main23923-64020i2L..LX70198505-198610

sub23923-64021

main23923-64021i2L..LX70198610-198808

13 parts on this diagram · 1 diagram in section
