REAR AXLE SHAFT & HUB

0001 1 0002 1W(LSD) 0003 1 0004 1 0005 1

4101

42330SHAFT ASSY, REAR DRIVE, RH

main42330-WAA04iDB0#¥153,000202003-202307

sub42330-WAA07¥103,000

main42330-WAA05iDB82¥103,000201903-202210

main42330-WAA06iDB2#,81¥103,000202210

42330GOIL SEAL, REAR DRIVE SHAFT, RH

main90118-WA520iDB82¥12,400201903-202210

main90118-WA521iDB0#¥5,600202003-202210

sub90118-WAA60¥10,400

42340DOIL SEAL, REAR DRIVE SHAFT, LH

main90118-WA520iDB82¥12,400201903-202210

main90118-WA521iDB0#¥5,600202003-202210

sub90118-WAA60¥10,400

90118WA262

main90118-WA262¥810

5 parts on this diagram · 5 diagrams in section
