CAUTION PLATE & NAME PLATE (ENGINE)

11277PLATE, ENGINE SPECIFICATION, NO.2

main11277-46070i2JZGTE..JZA80199305-199601

sub11277-46080

11283PLATE, TURBOCHARGER CAUTION

main11294-46020i2JZGTE..JZA80199305-199601

11286PLATE, ENGINE SPECIFICATION

main11286-46060i2JZGE..JZA80199305-199308

sub11286-46061

main11286-46061i2JZGE..JZA80199308-199605

11296ALABEL, ENGINE SERVICE INFORMATION

main11296-46091i2JZGE..JZA80199305-199605

main11296-46210i2JZGTE..JZA80199305-199601

11298PLATE, EMISSION CONTROL INFORMATION

main11298-46060i2JZGTE..JZA80..LHD199305-199408

SWEDEN OR FINLAND OR NORWAY SPEC

main11298-46060i2JZGTE..JZA80..LHD199408-199601

FINLAND OR NORWAY SPEC

15369PLATE, ENGINE OIL CAUTION

main15369-46010i2JZGTE..JZA80199305-199403

sub15369-46020

main15369-46020i2JZGTE..JZA80199403-199601

1356410010LABEL, TIMING BELT REPLACEMENT INFORMATION

main13564-10010

7 parts on this diagram · 1 diagram in section
