DISC WHEEL & WHEEL CAP

42601WHEEL, DISC

main42611-14580×2iMA70198808-199008

16X7JJ,LH,TYPE A

main42611-14590×2iMA70198808-199008

16X7JJ,RH,TYPE A

main42611-14610-03×4iMA70..C,GEN,V198908-199008

16X7JJ,TYPE B,SILVER,050 ,176 ,182 ,3E5 ,4K9

main42611-14680×2iMA70..C,EUR198808-198908

16X7JJ,WHITE PACKAGE,LH,TYPE A

main42611-14681×2iMA70..C198908-199008

16X7JJ,WHITE PACKAGE,LH,TYPE A

main42611-14690×2iMA70..C,EUR198808-198908

16X7JJ,WHITE PACKAGE,RH,TYPE A

main42611-14691×2iMA70..C198908-199008

16X7JJ,WHITE PACKAGE,RH,TYPE A

main42611-14800×4iMA70..LHD..(C,V)199008-199305

16X7JJ,SILVER,TYPE C

main42611-14810×4iMA70..SPR..5F..C199008-199305

16X7JJ,TYPE C

42601AWHEEL, DISC (FOR SPARE)

main42611-14580iMA70..RHD..(ARL,GEN)198808-199008

16X7JJ,LH,TYPE A

main42611-14590iMA70..LHD..(GEN,V)198808-199008

16X7JJ,RH,TYPE A

main42611-14600iMA70..C,EUR198808-199305

16X7JJ,TYPE A

main42611-14680iMA70..RHD..EUR198808-198908

16X7JJ,LH,TYPE A,WHITE PACKAGE

main42611-14681iMA70..RHD..C198908-199008

16X7JJ,TYPE A,WHITE PACKAGE

main42611-14690iMA70..LHD..(C,EUR)198808-198908

16X7JJ,RH,TYPE A,WHITE PACKAGE

main42611-14691iMA70..LHD..C198908-199008

16X7JJ,16X7JJ,TYPE A,WHITE PACKAGE

main42611-14800iMA70..ARL,GEN,V199008-199305

16X7JJ,TYPE C

42601CNUT, HUB (FOR AXLE)

main90942-01050×20iMA70198808-199008

main90942-01062×20iMA70199008-199305

42601DWEIGHT, BALANCE (FOR DISC WHEEL)

main90942-03146iMA70..TWT..C;MA70..ARL,GEN,V199008-199305

10G

main90942-03147iMA70..TWT..C;MA70..ARL,GEN,V199008-199305

15G

main90942-03148iMA70198808-199008

20G

main90942-03149iMA70198808-199008

25G

main90942-03150iMA70..TWT..C;MA70..ARL,GEN,V199008-199305

30G

main90942-03151iMA70198808-199008

35G

main90942-03152iMA70198808-199008

40G

main90942-03153iMA70..TWT..C;MA70..ARL,GEN,V199008-199305

45G

main90942-03154iMA70198808-199008

50G

main90942-03155iMA70..TWT..C;MA70..ARL,GEN,V199008-199305

55G

main90942-03156iMA70198808-199008

60G

main90942-03157iMA70..TWT..C;MA70..ARL,GEN,V199008-199305

65G

main90942-03158iMA70..TWT..C;MA70..ARL,GEN,V199008-199305

70G

main90942-03159iMA70..TWT..C;MA70..ARL,GEN,V199008-199305

75G

main90942-03160iMA70..TWT..C;MA70..ARL,GEN,V199008-199305

80G

main90942-03167iMA70198808-199008

5G

main90942-03208iMA70..TWT..C;MA70..ARL,GEN,V199008-199305

7.5G,T=6.1

main90942-03209iMA70198908-199008

12.5G,T=7.0

main90942-03210iMA70198908-199008

17.5G,T=8.0

main90942-03211iMA70..TWT..C;MA70..ARL,GEN,V199008-199305

22.5G,T=8.0

main90942-03212iMA70..TWT..C;MA70..ARL,GEN,V199008-199305

27.5G,T=8.0

main90942-03213iMA70198908-199008

32.5G,T=8.0

main90942-03214iMA70198908-199008

37.5G,T=8.0

42603ORNAMENT SUB-ASSY, WHEEL HUB

main42603-14210×4iMA70198808-199008

*ALU

main42603-14260-08×4iMA70..C,EUR198808-198908

WHITE PACKAGE,WHITE,043

main42603-14261-05×4iMA70..C198908-199008

WHITE PACKAGE,BEIGE M.,4K9

main42603-14261-08×4iMA70..C198908-199008

WHITE PACKAGE,WHITE,050

main42603-14300-03×4iMA70..TWT..C199008-199108

*ALU,SILVER,050 ,176 ,182 ,202 ,3E5 ,3H8 ,8J3

main42603-14310-03×4iMA70..TWT..C199108-199305

WHITE PACKAGE,DARK GRAY,050 ,182 ,202 ,3E5 ,3K3 ,6L9 ,749 ,8J3

main42603-14310-08×4iMA70..TWT..C199008-199305

WHITE PACKAGE,SUPER WHITE,050

42611GVALVE (FOR TUBELESS TIRE)

main90942-05004×4iMA70..TWT..C;MA70..ARL,GEN,V199008-199305

main90942-05009iMA70..C,EUR198808-199305

FOR SPARE TIRE

42652TIRE

main42652-14530×4iMA70..V198808-199008

225/50R16

main42652-14550×4iMA70..ARL,GEN198812-199008

225/50VR16

main42652-14680×4iMA70..TWT..C199008-199305

225/50ZR16

main42652-14760×4iMA70..V199008-199305

225/50R16 92V M.

42652ATIRE (FOR SPARE)

main42652-14530iMA70..V198808-199008

225/50R16

main42652-14550iMA70..ARL,GEN198812-199008

225/50VR16

main42652-14570iMA70..C,EUR198808-199305

205/55R16

main42652-14700iMA70..GEN199008-199305

225/50R16 92V

main42652-14760iMA70..V199008-199305

225/50R16 92V M.

8 parts on this diagram · 1 diagram in section
