ALTERNATOR

0001 112V 100A 0002 112V 80A 0003 112V 100A 0005 112V 80A

1107

27020ALTERNATOR ASSY

main27060-20210i1MZFE..MCV30200307-200406

12V 100A

main27060-20240i1MZFE..MCV30200108-200307

12V 100A

main27060-28180i1AZFE,2AZFE..ACV3#200108-200307

12V 80A

sub27060-28110

main27060-28280i1AZFE,2AZFE..ACV3#200307-200406

12V 80A

27039COVER, ALTERNATOR REAR END

main27039-20160i1MZFE..MCV30200108-200307

main27039-27060i1MZFE..MCV30200307-200601

main27039-31200i1AZFE,2AZFE..ACV3#200406-200601

27064SEAL, ALTERNATOR PLATE

main27064-42010i1MZFE..MCV30200108-200307

27310FRAME ASSY, DRIVE END, ALTERNATOR

main27310-20130i1MZFE..MCV30200307-200601

main27310-20170i1MZFE..MCV30200108-200307

main27310-28160i1AZFE,2AZFE..ACV3#200406-200601

27310BBEARING(FOR ALTERNATOR DRIVE END FRAME)

main90099-10142i1MZFE..MCV30200307-200406

sub90099-10223

main90099-10192i1MZFE..MCV30200108-200307

27312PLATE, RETAINER

main27312-42010i1MZFE..MCV30200108-200307

main27312-72100i1MZFE..MCV30200307-200601

27330ROTOR ASSY, ALTERNATOR

main27330-28050i1MZFE..MCV30200108-200307

main27330-30070i1MZFE..MCV30200307-200601

main27330-62220i1AZFE,2AZFE..ACV3#200307-200601

sub27330-30130

main27330-74550i1AZFE,2AZFE..ACV3#200108-200307

27330ABEARING(FOR ALTERNATOR ROTOR)

main90099-10140i1MZFE..MCV30200108-200406

main90099-10216i1AZFE,2AZFE..ACV3#200406-200601

27357HOLDER, ALTERNATOR, W/RECTIFIER

main27357-22050i1AZFE,2AZFE..ACV3#200108-200307

main27357-22200i1AZFE,2AZFE..ACV3#200307-200406

main27357-70450i1MZFE..MCV30200108-200307

27359FRAME, ALTERNATOR RECTIFIER END

main27359-20080i1MZFE..MCV30200108-200307

main27359-28160i1AZFE,2AZFE..ACV3#200406-200601

27365PLATE, TERMINAL

main27365-55080i1MZFE..MCV30200108-200307

27370HOLDER ASSY, ALTERNATOR BRUSH

main27370-58460i1MZFE..MCV30200307-200601

main27370-75060i1MZFE..MCV30200108-200601

27384WASHER

main27384-50030i1MZFE..MCV30200108-200601

27387INSULATOR, TERMINAL

main27387-42021i1MZFE..MCV30200108-200307

27388COVER, ALTERNATOR BRUSH

main27388-42010i1MZFE..MCV30200108-200307

27389INSULATOR, TERMINAL

main27389-42010i1MZFE..MCV30200108-200307

main27389-62220i1AZFE,2AZFE..ACV3#200406-200601

27411PULLEY, ALTERNATOR

main27411-28090i1AZFE,2AZFE..ACV3#200108-200307

main27411-28160i1AZFE,2AZFE..ACV3#200307-200601

main27411-46080i1MZFE..MCV30200108-200601

27443COVER, ALTERNATOR BEARING

main27443-63020i1MZFE..MCV30200108-200601

27700AREGULATOR ASSY, GENERATOR

main27700-28060i1AZFE,2AZFE..ACV3#200307-200601

main27700-46060i1AZFE,2AZFE,1MZFE..ACV3#,MCV30200108-200307

9009900195

main90099-00195

9009900197

main90099-00197

9009900243

main90099-00243

9009900246

main90099-00246

9009904966

main90099-04966

9009905119

main90099-05119

9009905171

main90099-05171

9009905172

main90099-05172

9017906158

main90179-06158

9331914025

main93319-14025

30 parts on this diagram · 4 diagrams in section
