ARMREST & VISOR

0001 1ARMREST 0002 1VISOR & ASSIST GRIP 0003 1ASSIST GRIP(LUGGAGE DOOR)

74231PANEL, FRONT ARMREST BASE, UPPER RH

main74230-33090-A0iAVV60,GSV60201206-201507

ECRU,TRIM00

main74230-33090-A1iASV60201206-201507

IVORY,TRIM0#

main74230-33090-C0iASV60201206-201507

BLACK,TRIM1#,2#

main74230-33120iASV6#,GSV60201507

74232PANEL, FRONT ARMREST BASE, UPPER LH

main74240-33100-A0iAVV60,GSV60201206-201507

ECRU,TRIM00

main74240-33100-A1iAVV60,GSV60201206-201507

IVORY,TRIM01

main74240-33100-C0iASV60201206-201507

BLACK,TRIM1#,2#

main74240-33130iASV6#,GSV60201507

74250ARMREST ASSY, REAR RH

main74250-33120-A0iAVV60,GSV60201206-201507

ECRU,TRIM00

main74250-33120-A1iAVV60,GSV60201206-201507

IVORY,TRIM01

main74250-33120-C0iAVV60,GSV60201206-201507

BLACK,TRIM1#,2#

main74250-33150iASV6#,GSV60201507

74260ARMREST ASSY, REAR LH

main74260-33120-A0iAVV60,GSV60201206-201507

ECRU,TRIM00

main74260-33120-A1iAVV60,GSV60201206-201507

IVORY,TRIM01

main74260-33120-C0iAVV60,GSV60201206-201507

BLACK,TRIM1#,2#

main74260-33160iASV6#,GSV60201507

74813CCLIP

main90467-10203×8iASV60,AVV60,GSV60201206-201507

5 parts on this diagram · 3 diagrams in section
