THROTTLE LINK & VALVE LEVER (ATM)

0001 1 0002 1 0003 1 0004 1

35501ROD SUB-ASSY, PARKING LOCK

main35501-32010iSV21..4FC198808-199106

main35501-32020iVZV21..4FC198808-199007

sub35501-32040

main35501-32040iVZV21..4FC199007-199106

35505LEVER SUB-ASSY, MANUAL VALVE

main35505-20010iSV21,VZV21..4FC198808-199106

sub35505-32040

main35505-32030iVZV21..4FC199007-199106

35505BSPACER (FOR MANUAL VALVE LEVER)

main90560-20006iSV21,VZV21..4FC198808-199106

35505GPIN, SLOTTED SPRING (FOR MANUAL VALVE LEVER)

main90254-04011iSV21,VZV21..4FC198808-199106

35506SHAFT SUB-ASSY, MANUAL VALVE LEVER

main35561-32010iSV21..4FC198808-199106

35506FSEAL, OIL (FOR MANUAL VALVE LEVER SHAFT)

main90311-12002iSV21,VZV21..4FC198808-199106

35506JSPRING, RETAINER (FOR MANUAL VALVE LEVER SHAFT)

main90524-09001iSV21,VZV21..4FC198808-199106

35556SHAFT, PARKING LOCK PAWL

main35556-32010iSV21..4FC198808-199106

main35556-32020iVZV21..4FC198808-199106

35557PAWL, PARKING LOCK

main35557-32020iSV21..4FC198808-199106

main35557-32030iVZV21..4FC198808

35557ASPRING, TORSION (FOR PARKING LOCK PAWL)

main90508-26047iSV21..4FC198808-199106

main90508-33001iVZV21..4FC198808

35572ALEVER, TRANSMISSION CONTROL SHAFT

main35572-32011iVZV21..4FC198808-199106

main35572-32020iSV21..4FC198808-199106

35595BRACKET, PARKING LOCK PAWL

main35595-32010iSV21..4FC198808-199106

main35595-32020iVZV21..4FC198808-199106

9161160614

main91611-60614

9411050800

main94110-50800

9451200800

main94512-00800

15 parts on this diagram · 4 diagrams in section
