DISC WHEEL & WHEEL CAP
42601WHEEL, DISC
15X6JJ,TYPE F:REFER TO ILLUSTRATION,40TH ANNIVERSARY PACKAGE
sub42611-33190
15X6JJ,OFFSET 45,TYPE I:REFER TO ILLUSTRATION
14X5.5JJ,TYPE A:REFER TO ILLUSTRATION,BLACK
sub42611-32260
15X6JJ,OFFSET 45,#,TYPE B:REFER TO ILLUSTRATION,BLACK
sub42611-33011
15X6JJ,OFFSET 45,TYPE C:REFER TO ILLUSTRATION
14X5.5JJ,TYPE D:REFER TO ILLUSTRATION
16X6JJ,OFFSET 45,TYPE G:REFER TO ILLUSTRATION
42601AWHEEL, DISC (FOR SPARE)
15X6JJ,OFFSET 45,#,TYPE B:REFER TO ILLUSTRATION,BLACK
sub42611-33011
16X6JJ,0FFSET 45,TYPE H:REFER TO ILLUSTRATION
42601CNUT, HUB (FOR AXLE)
TYPE A:REFER TO ILLUSTRATION
TYPE B:REFER TO ILLUSTRATION
TYPE C:REFER TO ILLUSTRATION
TYPE C:REFER TO ILLUSTRATION,40TH ANNIVERSARY PACKAGE
42611GVALVE (FOR TUBELESS TIRE)
42611JVALVE (FOR TUBELESS TIRE SPARE)
42652TIRE
205/65R15 92H,*B/S
205/60R16 91H,*B/S
42652ATIRE (FOR SPARE)
205/65R15 92H,*B/S
205/60R16 91H,*B/S
7 parts on this diagram · 3 diagrams in section
