THROTTLE LINK & VALVE LEVER (ATM)

0001 1U151E,U241E 0002 1U341E

35501ROD SUB-ASSY, PARKING LOCK

main35501-21010iAZT25#..ATM200301-200604

main35501-52020iZZT251..4FC200301-200604

sub35501-52021

35505LEVER SUB-ASSY, MANUAL VALVE

main35505-20030iZZT251..4FC200301-200604

main35505-21010iAZT25#..ATM200301-200604

35505BSPACER (FOR MANUAL VALVE LEVER)

main90560-20006iAZT25#,ZZT251..ATM200301-200604

35505GPIN, SLOTTED SPRING (FOR MANUAL VALVE LEVER)

main90254-04011iAZT25#..ATM200301-200604

35506FSEAL, OIL (FOR MANUAL VALVE LEVER SHAFT)

main90311-12002iAZT25#,ZZT251..ATM200301-200604

35506JSPRING, RETAINER (FOR MANUAL VALVE LEVER SHAFT)

main90524-09001iAZT25#,ZZT251..ATM200301-200604

35556SHAFT, PARKING LOCK PAWL

main35556-28010iAZT251200309-200604

main35556-32020iZZT251..4FC200301-200604

main35556-32030iAZT250..4FC200301-200604

35557PAWL, PARKING LOCK

main35557-52020iZZT251..4FC200301-200604

sub35557-52021

main35590-21010iAZT251200309-200604

main35590-32010iAZT250..4FC200301-200604

35557ASPRING, TORSION (FOR PARKING LOCK PAWL)

main90506-18077iAZT25#..ATM200301-200604

main90949-03089iZZT251..4FC200301-200604

35558CLAMP, PAWL SHAFT

main35558-28010iAZT251200309-200604

main35558-32010iAZT250..4FC200301-200604

35561SHAFT, MANUAL VALVE LEVER

main35561-21010iAZT25#..ATM200301-200604

main35561-52020iZZT251..4FC200301-200604

35572ALEVER, TRANSMISSION CONTROL SHAFT

main35572-20250iZZT251..4FC200301-200604

main35572-28100iAZT251200309-200604

sub35572-48010

main35572-48010iAZT250..4FC200301-200604

35579PIN, PARKING LOCK PAWL

main35594-21010iAZT250..4FC200301-200604

main35594-28010iAZT251200309-200604

35595BRACKET, PARKING LOCK PAWL

main35595-21010iAZT25#..ATM200301-200604

main35595-52020iZZT251..4FC200301-200604

8401

9010506053

main90105-06053

9010506079

main90105-06079

9011908668

main90119-08668

9011908891

main90119-08891

9413000802

main94130-00802

9451200800

main94512-00800

21 parts on this diagram · 2 diagrams in section
