REAR OIL PUMP & GOVERNOR (ATM)

35145AADAPTER, GOVERNOR PRESSURE

main35145-32010iAT151,ST150..3FC198310-198411

sub35145-32011

main35145-32011iAT151,ST150..3FC198411-198711

35145BSPRING, TORSION(FOR GOVERNOR PRESSURE ADAPTER)

main90508-18034iAT151,ST150..3FC198310-198711

35149COVER, GOVERNOR

main35149-12010iAT151..3FC198310-198711

main35149-20010iAT151,ST15#..4FC198401-198711

main35149-32010iST150..3FC198310-198711

35149ARING, O (FOR GOVERNOR COVER)

main90301-67001iST150..3FC198310-198711

main90301-68001iAT151,ST15#..4FC198401-198711

main90301-73001iAT151..3FC198310-198711

35157AADAPTER, GOVERNOR BODY

main35157-12010iAT151..3FC198310-198711

main35157-20030iAT151..4FC198401-198411

sub35157-20031

main35157-20031iAT151,ST15#..4FC198411-198711

main35157-32010iST150..3FC198310-198407

sub35157-32011

sub90201-25003

main35157-32011iST150..3FC198407-198711

35188ABRACKET, GOVERNOR COVER

main35188-12010iAT151..3FC198310-198711

main35188-20010iAT151,ST15#..4FC198401-198711

main35188-32011iST150..3FC198310-198711

35189WASHER, GOVERNOR THRUST, NO.1

main35189-32010iAT151,ST15#..ATM198310-198711

sub35189-32011

35480FBODY ASSY, GOVERNOR

main35480-20020iAT151..4FC198401-198412

sub35480-20021

main35480-20021iAT151,ST15#..4FC198412-198711

main35480-32010iAT151,ST150..3FC198310-198412

sub35480-32011

main35480-32012iAT151,ST150..3FC198412-198711

sub35480-32013

35480GWASHER, PLATE (FOR GOVERNOR BODY)

main90201-25003iAT151,ST150..3FC198407-198711

T=1.0

main90201-25003iAT151..3FC198310-198407

main90201-26004iST150..3FC198310-198407

T=1.6

35489CGEAR, GOVERNOR DRIVEN

main35489-12010iAT151,ST15#..4FC198401-198711

35779GEAR, GOVERNOR DRIVE

main35779-32010iAT151,ST150..3FC198310-198711

9161140816

main91611-40816

9161160614

main91611-60614

9161160814

main91611-60814

14 parts on this diagram · 1 diagram in section
