FRONT BUMPER & BUMPER STAY

0001 1 0002 1 0003 1 0004 1

52021REINFORCEMENT SUB-ASSY, FRONT BUMPER

main52021-14090iRA6#,TA60198108-198308

main52021-14100iMA61198112-198512

main52021-14120iAA63,RA6#,SA63,TA60198308-198507

52115ASUPPORT, FRONT BUMPER SIDE, RH

main52115-14080iRA6#,TA60198108-198308

main52115-14100iAA63,RA6#,SA63,TA60198308-198507

52115CCAP, FRONT BUMPER, SIDE SUPPORT

main90386-07007×4iAA63,RA6#,SA63,TA60198108-198507

52116ASUPPORT, FRONT BUMPER SIDE, LH

main52116-14060iRA6#,TA60198108-198308

main52116-14070iAA63,RA6#,SA63,TA60198308-198507

52119ACOVER, FRONT BUMPER

main52119-14150iTA60..LT198108-198308

main52119-14160iTA60..LT..EUG198108-198308

W/*HC

main52119-14901iMA61198112-198308

main52119-14902iRA6#,TA60..GT,ST,XT198108-198308

main52119-14903iRA61,63,TA60..(GT,ST,XT)..EUR198108-198308

W/*HC

main52119-14904iAA63,RA6#,SA63,TA60198308-198507

main52119-14905iMA61198308-198512

main52119-14906iAA63,RA61,TA60..EUR198308-198507

*HC

52521RETAINER, FRONT BUMPER, UPPER CENTER

main52521-14050iRA6#,TA60198108-198308

main52521-14060iMA61198112-198512

main52521-14070iAA63,RA6#,SA63,TA60198308-198507

52522RETAINER, FRONT BUMPER UPPER SIDE

main52522-14030×2iRA6#,TA60198108-198308

52525RETAINER, FRONT BUMPER, LOWER CENTER

main52506-14010iRA6#,TA60198108-198112

sub75111-14070

sub91655-40618

main52506-14011iRA6#,TA60198112-198308

main52506-14020iAA63,RA6#,SA63,TA60198308-198507

main52525-14070iMA61198112-198408

main52525-14071iMA61198408-198512

52525BRETAINER, FRONT BUMPER, LOWER SIDE RH

main52526-14030iRA6#,TA60198108-198308

main52526-20010iMA61198308-198512

52526BRETAINER, FRONT BUMPER, LOWER SIDE LH

main52526-14030iRA6#,TA60198108-198308

main52526-20010iMA61198308-198512

52611ABSORBER, FRONT BUMPER ENERGY

main52611-14060iRA6#,TA60198108-198308

main52611-14070iMA61198112-198512

main52611-14080iAA63,RA6#,SA63,TA60198308-198507

9010512032

main90105-12032

9011914003

main90119-14003

9017906068

main90179-06068

9017912021

main90179-12021

9018303001

main90183-03001

9165540620

main91655-40620

17 parts on this diagram · 4 diagrams in section
