THROTTLE LINK & VALVE LEVER (ATM)

3312

35501ROD SUB-ASSY, PARKING LOCK

main35501-50020iUSE20200712

35505LEVER SUB-ASSY, MANUAL VALVE

main35505-30040iUSE20200712

35506CPIN, SLOTTED SPRING (FOR MANUAL VALVE LEVER SHAFT)

main90254-04011iUSE20200712

35506FSEAL, OIL (FOR MANUAL VALVE LEVER SHAFT)

main90311-12002iUSE20200712

35506HSPACER (FOR MANUAL VALVE LEVER SHAFT)

main90560-20025iUSE20200712

35556SHAFT, PARKING LOCK PAWL

main35556-60020iUSE20200712

35556CSPRING, TORSION (FOR PARKING LOCK PAWL SHAFT)

main90949-03147iUSE20200712

35556ERING, E (FOR PARKING LOCK PAWL SHAFT)

main90523-08021iUSE20200712

35557PAWL, PARKING LOCK

main35590-50020iUSE20200712

35561SHAFT, MANUAL VALVE LEVER

main35561-50030iUSE20200712-201408

35572LEVER, TRANSMISSION CONTROL SHAFT, RH

main35572-30100iUSE20200712

35595BRACKET, PARKING LOCK PAWL

main35595-50020iUSE20200712

9010508449

main90105-08449

9413000802

main94130-00802

9451200800

main94512-00800

16 parts on this diagram · 1 diagram in section
