DISC WHEEL & WHEEL CAP

0001 1 0002 1

42601WHEEL, DISC

main42611-47030×4iNHW11200005

14X5.5JJ,TYPE A:REFER TO ILLUSTRATION

42601AWHEEL, DISC (FOR SPARE)

main42611-1A010iNHW11200005

15X4T,TYPE B:REFER TO ILLUSTRATION

main42611-47030iNHW11200005

14X5.5JJ,TYPE A:REFER TO ILLUSTRATION

42601CNUT, HUB (FOR AXLE)

main90942-01033×16iNHW11200005

42603ORNAMENT SUB-ASSY, WHEEL HUB

main42603-20620×4iNHW11200005

*ALU,TYPE A:REFER TO ILLUSTRATION

42611GVALVE (FOR TUBELESS TIRE)

main90942-05009×4iNHW11200005

42611JVALVE (FOR TUBELESS TIRE SPARE)

main90942-05009iNHW11200005

42652TIRE

main42652-47040×4iNHW11..ARL200108

175/65R14

main42652-52040×4iNHW11..LHD200005

155/80R13 82T

sub42652-52041

main42652-52060×4iNHW11..RHD..EUR200005

175/65R14

sub42652-52061

42652ATIRE (FOR SPARE)

main42652-40040iNHW11200005

T135/70D15

main42652-47040iNHW11..ARL200108

175/65R14

main42652-52040iNHW11..LHD200005

155/80R13 82T

sub42652-52041

main42652-52060iNHW11..RHD..EUR200005

175/65R14

sub42652-52061

8 parts on this diagram · 2 diagrams in section
