FRONT BUMPER & BUMPER STAY

0001 1 0002 1

52021REINFORCEMENT SUB-ASSY, FRONT BUMPER

main52021-14060iCA60,TA6#198108-198309

main52021-14080iCA60,TA6#..CP,SED198108-198309

URETHANE BUMPER

52115ASUPPORT, FRONT BUMPER SIDE, RH

main52115-14061iCA60,TA6#198108-198309

main52115-14070iCA60,TA6#..CP,SED198108-198309

URETHANE BUMPER

52116ASUPPORT, FRONT BUMPER SIDE, LH

main52116-14041iCA60,TA6#198108-198309

main52116-14050iCA60,TA6#..CP,SED198108-198309

URETHANE BUMPER

52119ACOVER, FRONT BUMPER

main52119-14080iCA60,TA6#198208-198309

W/O *HC

main52119-14090iCA60,TA6#..EUR198108-198309

W/*HC

main52119-14110iTA62..EUG;CA60,TA60..CP,SED198108-198208

URETHANE BUMPER,W/O *HC

main52119-14120iCA60,TA6#..(CP,SED)..EUR198108-198309

URETHANE BUMPER,W/*HC

52701MOULDING SUB-ASSY, FRONT BUMPER

main52711-14020iTA6#..GL198108-198309

main52711-14030iCA60,TA6#..DLX,XE198108-198309

9011910240

main90119-10240

9046804029

main90468-04029

9165540620

main91655-40620

9165561030

main91655-61030

9356815012

main93568-15012

10 parts on this diagram · 2 diagrams in section
