CAUTION PLATE & NAME PLATE (ENGINE)

11291PLATE, ENGINE NAME

main11291-26020i2T..TA60198108-198309

2T

main11291-28020i3T..TA62198108-198309

3T

main11291-28040i3TC..TA62198108-198309

3T-C

11293PLATE, ENGINE CAUTION & ENGINE NAME

main11293-64010i1C..CA60198204-198309

11296PLATE, TIMING BELT CAUTION

main11296-54010i1C..CA60198204-198309

11298PLATE, EMISSION CONTROL INFORMATION

main11298-28052i3TC..TA62198108-198208

main11298-28120i3TC..TA62198208-198309

SWITZLAND SPEC

main11298-28130i3TC..TA62198208-198309

SWEDEN SPEC

11299PLATE, IDLE ADJUSTING CAUTION

main11299-28020i3TC..TA62198210-198309

SWITZERLAND SPEC

17627PLATE, AIR PUMP CAUTION, NO.1

main90917-07066i3TC..TA62198108-198110

main90917-07075i3TC..TA62198110-198309

17700CPLATE, AIR CLEANER CAUTION (FOR ENGINE MODEL)

main17791-64020i1C..CA60198305-198309

main90917-07088i1C..CA60198204-198305

17700DPLATE, ENGINE CAUTION

main11293-25027i2T,3T..TA6#198108-198309

main17791-28010i3TC..TA62198108-198309

sub17791-16040

17792PLATE, ENGINE VACUUM HOSE INFORMATION

main17792-28061i3TC..TA62198108-198208

main17792-28130i3TC..TA62198208-198309

9 parts on this diagram · 1 diagram in section
