REAR AXLE SHAFT & HUB

0001 1RH 0002 1 0003 1LH 0004 1RH 0005 1LH

04438CBOOT KIT, REAR DRIVE SHAFT

main04437-17060iSW20..TWC¥10,800198912-199311

sub04438-20090¥10,800

main04438-20070iSW20..HTWC¥10,800198912-199208

main04438-20090iSW20¥10,800199311

04438DBOOT KIT, REAR DRIVE SHAFT INBOARD JOINT

main04437-17050iSW20..TWC¥6,700198912-199311

sub04438-20080¥6,700

main04438-20060iSW20..HTWC¥6,700198912-199208

sub04438-20330¥6,700

main04438-20080iSW20¥6,700199311

41336CCOVER, DUST(FOR REAR DRIVE SHAFT)

main41336-32010iSW20¥200198912

RH

main41336-32020iSW20¥310198912

LH

42330SHAFT ASSY, REAR DRIVE, RH

main42330-17090iSW20..TWC¥69,400198912-199101

sub42330-17091¥68,800

sub43525-20040¥300

sub90179-22020¥310

main42330-17091iSW20..TWC¥68,800199101-199709

sub42330-17092¥68,900

sub90178-22001¥310

main42330-17092iSW20¥68,900199709-199712

sub42330-17102¥68,900

main42330-17100iSW20..TWC¥69,400198912-199101

W(*66)

sub42330-17101¥68,800

sub43525-20040¥300

sub90179-22020¥310

main42330-17101iSW20..TWC¥68,800199101-199709

W(*66)

sub42330-17102¥68,900

sub90178-22001¥310

main42330-17102iSW20¥68,900199709

W(*66)

main42330-17110iSW20..HTWC¥69,400198912-199101

sub42330-17111¥68,700

sub43525-20040¥300

sub90179-22020¥310

main42330-17111iSW20..HTWC¥68,700199101-199208

sub42330-17112¥68,200

sub90178-22001¥310

main42330-17120iSW20..HTWC¥69,400198912-199101

W(*66)

sub42330-17121¥68,700

sub43525-20040¥300

sub90179-22020¥310

main42330-17121iSW20..HTWC¥68,700199101-199208

W(*66)

sub42330-17122¥68,200

sub90178-22001¥310

42330CRING, HOLE SNAP(FOR REAR DRIVE SHAFT)

main90521-27005iSW20¥110198912

42346ACLAMP (FOR REAR DRIVE SHAFT OUTBOARD JOINT BOOT)

main90949-01108iSW20..TWC¥320198912

ID=33.6

main90949-01559iSW20..HTWC¥320198912-199208

ID=33.74

42346BCLAMP, NO. 2 (FOR RR DRIVE SHAFT OUTBOARD JOINT BOOT)

main90949-01107iSW20..TWC¥540198912

main90949-01473iSW20..HTWC¥260198912-199208

42347ACLAMP (FOR REAR DRIVE SHAFT INBOARD JOINT BOOT)

main90949-01108iSW20..TWC¥320198912

ID=33.6

main90949-01559iSW20..HTWC¥320198912-199208

ID=33.74

42347BCLAMP, NO.2 (FOR REAR DRIVE SHAFT INBOARD JOINT BOOT)

main42345-30010iSW20..HTWC¥970198912-199208

main42346-22010iSW20..TWC¥620198912

42350CRING, SNAP (FOR REAR DRIVE SHAFT OUTBOARD JOINT)

main90520-25034iSW20..TWC¥160198912

main90520-26048iSW20..HTWC¥120198912-199208

42350DJOINT ASSY, REAR DRIVE SHAFT OUTBOARD, RH

main43460-19375iSW20..HTWC¥47,800198912-199101

sub43460-19376¥47,300

sub43525-20030¥300

sub90179-22020¥310

main43460-19376iSW20..HTWC¥47,300199101-199208

sub43460-19377¥47,300

sub90178-22001¥310

main43460-19385iSW20..HTWC¥47,800198912-199101

W(*66)

sub43460-19386¥47,300

sub43525-20030¥300

sub90179-22020¥310

main43460-19386iSW20..HTWC¥47,300199101-199208

W(*66)

sub43460-19387¥47,300

sub90178-22001¥310

main43460-19395iSW20..TWC¥47,800198912-199101

sub43460-19396¥47,300

sub43525-20030¥300

sub90179-22020¥310

main43460-19396iSW20..TWC¥47,300199101-199606

sub43460-19397¥47,300

main43460-19397iSW20¥47,300199606-199709

sub43460-19398¥47,500

sub90178-22001¥310

main43460-19398iSW20¥47,500199709-199712

main43460-19405iSW20..TWC¥47,800198912-199101

W(*66)

sub43460-19406¥47,300

sub43525-20030¥300

sub90179-22020¥310

main43460-19406iSW20..TWC¥47,300199101-199606

W(*66)

sub43460-19407¥47,300

main43460-19407iSW20¥47,300199606-199709

W(*66)

sub43460-19408¥47,500

sub90178-22001¥310

main43460-19408iSW20¥47,500199709

W(*66)

42360ARING, SHAFT SNAP (FOR REAR DRIVE SHAFT INBOARD JOINT)

main90520-25033iSW20..TWC¥140198912-199606

main90520-25037iSW20..HTWC¥180198912-199208

42360BRING, SNAP (FOR REAR DRIVE SHAFT INBOARD JOINT)

main90521-79001iSW20..TWC¥280198912

42360CJOINT ASSY, REAR DRIVE SHAFT INBOARD, RH

main43030-17010iSW20..TWC¥27,900198912

main43030-17020iSW20..HTWC¥27,700198912-199208

43474BDAMPER, REAR DRIVE SHAFT

main43474-12020iSW20¥4,940198912

43474CCLAMP (FOR REAR DRIVE SHAFT DAMPER)

main42345-14010iSW20¥700198912-199307

main42345-16030iSW20¥660199307

16 parts on this diagram · 5 diagrams in section
