THROTTLE LINK & VALVE LEVER (ATM)

0001 1 0002 1

35505LEVER SUB-ASSY, MANUAL VALVE

main35505-22020iAE86..4FC198305-198308

main35505-22030iAE86..4FC198308-198312

sub35505-22040

main35505-22040iAE86..4FC198312-198704

35506SHAFT SUB-ASSY, MANUAL VALVE LEVER

main35561-40010iAE86..4FC198305-198704

35506CPIN, SLOTTED SPRING (FOR MANUAL VALVE LEVER SHAFT)

main90254-04011iAE86..4FC198305-198704

35506FSEAL, OIL (FOR MANUAL VALVE LEVER SHAFT)

main90311-11001iAE86..4FC198308-198704

sub90311-11003

main90311-11128iAE86..4FC198305-198308

sub90311-11001

35506HSPACER (FOR MANUAL VALVE LEVER SHAFT)

main90560-20003iAE86..4FC198305-198704

sub90560-20025

35556SHAFT, PARKING LOCK PAWL

main35556-22010iAE86..4FC198305-198508

sub35556-26010

main35556-26010iAE86..4FC198508-198704

35556ERING, E (FOR PARKING LOCK PAWL SHAFT)

main90523-08021iAE86..4FC198305-198704

35557PAWL, PARKING LOCK

main35557-35010iAE86..4FC198305-198704

35557ASPRING, TORSION (FOR PARKING LOCK PAWL)

main90508-25001iAE86..4FC198305-198704

35585ROD, PARKING LOCK

main35501-22020iAE86..4FC198305-198704

35595BRACKET, PARKING LOCK PAWL

main35595-16010iAE86..4FC198305-198310

sub35595-22020

main35595-40010iAE86..4FC198310-198704

9010106416

main90101-06416

9411050800

main94110-50800

9451200800

main94512-00800

9454200600

main94542-00600

15 parts on this diagram · 2 diagrams in section
