THROTTLE LINK & VALVE LEVER (ATM)

0001 1A132L 0002 1A132L 0003 1A240L,A245E 0004 1A240L

35501ROD SUB-ASSY, PARKING LOCK

main35501-12010iAE111..JPP..4FC199704-200110

main35501-32030iEE111..JPP..3FC199704-199911

35505LEVER SUB-ASSY, MANUAL VALVE

main35505-12040iAE111..UKP..4FC199704-199911

main35505-12070iZZE112..4FC199910-200110

main35505-32040iEE111..JPP..3FC199704-199911

35505BSPACER (FOR MANUAL VALVE LEVER)

main90560-20006iZZE112..4FC;AE111,EE111..UKP..ATM199704-200110

35505GPIN, SLOTTED SPRING (FOR MANUAL VALVE LEVER)

main90254-04011iZZE112..4FC;AE111,EE111..UKP..ATM199704-200110

35506FSEAL, OIL (FOR MANUAL VALVE LEVER SHAFT)

main90311-12002iZZE112..4FC;AE111,EE111..UKP..ATM199704-200110

35506JSPRING, RETAINER (FOR MANUAL VALVE LEVER SHAFT)

main90524-09001iEE111..UKP..3FC199704-199911

main90524-11001iZZE112..4FC;AE111..UKP..4FC199704-200110

35556SHAFT, PARKING LOCK PAWL

main35556-12020iZZE112..4FC;AE111..UKP..4FC199704-200110

main35556-32010iEE111..JPP..3FC199704-199911

35557PAWL, PARKING LOCK

main35557-12020iZZE112..4FC;AE111..UKP..4FC199704-200110

main35557-32020iEE111..JPP..3FC199704-199911

35557ASPRING, TORSION (FOR PARKING LOCK PAWL)

main90508-21003iAE111..JPP..4FC199704-200110

main90508-26047iEE111..JPP..3FC199704-199911

35561SHAFT, MANUAL VALVE LEVER

main35561-12020iAE111..JPP..4FC199704-199911

main35561-12030iZZE112..4FC199910-200110

main35561-32010iEE111..UKP..3FC199704-199911

35572ALEVER, TRANSMISSION CONTROL SHAFT

main35572-12110iEE111..JPP..3FC199704-199911

main35572-12120iAE111..UKP..4FC199704-199911

main35572-12130iZZE112..4FC199910-200109

sub35572-12150

main35572-12150iZZE112..4FC200109-200110

35595BRACKET, PARKING LOCK PAWL

main35595-32010iEE111..UKP..3FC199704-199911

9161160614

main91611-60614

9411050800

main94110-50800

9451200800

main94512-00800

15 parts on this diagram · 4 diagrams in section
