REAR AXLE SHAFT & HUB
04438CBOOT KIT, REAR DRIVE SHAFT
TYPE B:REFER TO ILLUSTRATION
04438DBOOT KIT, REAR DRIVE SHAFT INBOARD JOINT
42340SHAFT ASSY, REAR DRIVE
42341ARING, SNAP (FOR REAR DRIVE SHAFT)
TYPE A:REFER TO ILLUSTRATION
TYPE B:REFER TO ILLUSTRATION
42343COVER, OUTBOARD JOINT END
42346ACLAMP (FOR REAR DRIVE SHAFT OUTBOARD JOINT BOOT)
ID=32.7
42346BCLAMP, NO. 2 (FOR RR DRIVE SHAFT OUTBOARD JOINT BOOT)
42347ACLAMP (FOR REAR DRIVE SHAFT INBOARD JOINT BOOT)
ID=35.75
42347BCLAMP, NO.2 (FOR REAR DRIVE SHAFT INBOARD JOINT BOOT)
42350JOINT ASSY, REAR DRIVE SHAFT OUTBOARD
42370SHAFT ASSY, REAR DRIVE OUTBOARD JOINT
TYPE A:REFER TO ILLUSTRATION
TYPE A:REFER TO ILLUSTRATION,W(ABS)
TYPE B:REFER TO ILLUSTRATION
TYPE B:REFER TO ILLUSTRATION,W(ABS)
42451ADEFLECTOR, REAR WHEEL BEARING DUST, NO.1 RH
W(ABS)
42451BDEFLECTOR, REAR WHEEL BEARING DUST, NO.1 LH
W(ABS)
9017010191
9451101000
15 parts on this diagram · 3 diagrams in section
