ABS & VSC

5801

85999MBRACKET, RELAY

main85999-16100iEP81..LHD¥610199312-199601

88263ARELAY, SKID CONTROL

main88263-12070iEP8#..LHD¥6,600199201-199601

sub88263-12080¥6,700

main88263-12090iEP8#..LHD¥6,600198912-199201

89411SENSOR, SPEED

main89542-10010iEP8#..LHD¥21,700198912-199601

FRONT,RH

main89543-10010iEP8#..LHD¥21,700198912-199601

FRONT,LH

main89545-10010iEP8#..LHD¥21,700198912-199601

REAR,RH

main89546-10010iEP8#..LHD¥21,700198912-199601

REAR,LH

89540COMPUTER ASSY, SKID CONTROL

main89541-10010iEP8#..LHD¥59,800198912-199601

89547ARELAY, SKID CONTROL W/BRACKET

main88263-16010iEP81..LHD¥6,600199312-199601

main89547-10010iEP8#..LHD¥6,700198912-199312

89549BRACKET, SKID CONTROL COMPUTER

main88267-10020iEP8#..LHD¥820198912-199601

NO.1

main88268-10020iEP8#..LHD¥870198912-199601

NO.2

9011906120

main90119-06120¥70

9017906009

main90179-06009¥120

9046707109

main90467-07109¥170

91611A0614

main91611-A0614¥120

9165140614

main91651-40614¥160

9165140616

main91651-40616¥60

91651B0620

main91651-B0620¥70

9326954010

main93269-54010¥60

15 parts on this diagram · 1 diagram in section
