ANTENNA

86101CORD SUB-ASSY, ANTENNA

main86101-10030iKP6#197802-198005

sub86101-10031

main86101-10031iKP6#198005-198409

86300ANTENNA ASSY, W/HOLDER

main86300-10100iKP6#..RHD197802-198005

main86300-10101iKP6#..RHD198005-198409

main86300-10110iKP6#..LHD197802-198005

main86300-10111iKP6#..LHD198005-198409

main86300-10130iKP60..EUG;KP61..SED..EUR198208-198409

86309POLE SUB-ASSY, PILLAR ANTENNA

main86309-10010iKP6#..RHD197802-198005

main86309-10011iKP6#..RHD..GEN198005-198409

main86309-10020iKP6#..LHD197802-198005

main86309-10021iKP6#..LHD..GEN198005-198409

86391HOLDER, ANTENNA

main86391-10040iKP6#197802-198409

86396NUT, ANTENNA

main90179-12026iKP60..EUG;KP61..SED..EUR198208-198409

86399ACAP, ANTENNA

main86399-10010iKP60..EUG;KP61..SED..EUR198208-198409

9015940033

main90159-40033

9016040033

main90160-40033

9165140614

main91651-40614

9351014020

main93510-14020

10 parts on this diagram · 1 diagram in section
